Contains 11-5/32" Diameter balls.

May be ordered with light oil or grease packed lubricant.

Contains 11-5/32" Diameter balls.

May be ordered with light oil or grease packed lubricant.

Products specifications
(A) Bearing Body Diameter 1.281" - 1.291"
(B) Bearing Insertion Depth 0.3438 (11/32")
(C) Bore Extension 0.2188" (7/32")
(D) Length through Bore 0.562" (9/16")
(E) Flange Diameter 1.37" (1-3/8")
BORE SIZE 0.255/0.252" (1/4" Round)
Load Rating 47#
Tube Size / Material (!!REF. ONLY!!) 1-3/8"O.D. x 18ga Steel (1.277" I.D.)
Weight / 1,000 pcs 81.25 Lbs (36.85 kg)
