Contains 11- 1/4" Diameter balls.

May be ordered with light oil or grease packed lubricant.

T added to the end of the part number designates a nylatron seal added to the front of the bearing.

Bore dimensions are interchangeable throughout F-series 1625-1775 bearings.

!!~~UNCOMMON BORE SIZE~~!!
PLEASE CALL FOR AVAILABILITY
MINIMUM ORDERS MAY BE REQUIRED

Contains 11- 1/4" Diameter balls.

May be ordered with light oil or grease packed lubricant.

T added to the end of the part number designates a nylatron seal added to the front of the bearing.

Bore dimensions are interchangeable throughout F-series 1625-1775 bearings.

!!~~UNCOMMON BORE SIZE~~!!
PLEASE CALL FOR AVAILABILITY
MINIMUM ORDERS MAY BE REQUIRED

Products specifications
(A) Bearing Body Diameter 1.701" -1.711"
(B) Bearing Insertion Depth 0.3594" (23/64")
(C) Bore Extension 0.2500" (1/4")
(D) Length through Bore 0.609" (39/64")
(E) Flange Diameter 1.84" (1-27/32")
Load Rating 135#
Weight / 1,000 pcs 175 Lbs (79.37 kg)
Tube Size / Material (!!REF. ONLY!!) 1.9"O.D. x 12ga (1.682" I.D.)
